STICKY Jeep Wrangler YJ Factory Service Manuals (FSM) and Part Catalogs

[Flyer58]

Any thoughts on this? I also have a 92YJ and don’t see that year for anything but Body/Chassis.

I did not find any difference when working on my 92 with a 2.4L and AX5



[machoheadgames]

Any thoughts on this? I also have a 92YJ and don’t see that year for anything but Body/Chassis.

There are minor differences between those years but nothing significant. Use it.



[hbar]

Working on overhauling a 32RH, and came across this bogus torque spec in the 1989 FSM. Clearly that should be175 inch-pounds, not 175 foot-pounds. Interestingly, the ATSG manual makes a similar mistake on the pump bolt torque (foot pounds when they meant to say inch pounds). Trust me when I tell you that you don't want to torque small bolts into an aluminum case at 175 foot-pounds! (also, ask me how I know).



[dieselearl]

Chris, thanks for all the work you done.



[v8haha]

Hi Chris, I am in need of the FSM for an 89 Wrangler with the 4.2l, I only see the parts catalog attached above.



[Avail211]

I know this is a super old thread, but I want to thank OP for the docs. They have helped IMMENSELY while I repair this 93 YJ I acquired.
